DATA
| Conductor: | Annealed Tinned Copper (APC Optional) according to IEC 60228, Class 5 or as per customer order |
| Insulation: | EBXL – XLPO 120˚C |
| Jacket: | EBXL- XLPO Highly Weather & UV Resistant |
| Test Voltage: | 6500V AC for 5 minutes |
| Voltage Resistance Test: | EN 50395 |
| Rated Voltage: | 600/1000 V AC, 1800 V DC, 1.5 kV DC |
| Short Circuit Temp: | +280°C. |
Resistance against UV, Water, Ozone, Fluids, Oil, Salt & General Weathering.
Electron Beam Cross Linked, Halogen Free, Flame Retardant, Low Smoke Emission
Fire retardant to meet IEC 607541-1/EN 50268-2
RoHS compliant as per EU norms
Max.Temp. at Conductor : 120˚C (20,000h)
