DATA

Peak power, (0 ~+ 4.99 Wp) Pmax (Wp)		355	360	365	370	375
Electrical data – All data measured to STC*
Maximum voltage, Vmpp	(V)	38.68	38.85	39.01	39.16	39.34
Maximum current, Impp	(A)	9.17	9.25	9.36	9.46	9.55
Open circuit voltage, Voc	(V)	46.88	47.07	47.31	47.47	47.67
Short circuit current, Isc	(A)	9.85	9.88	9.90	9.96	10.10
Module efficiency (%)	00	17.59	17.84	18.09	18.34	18.58
Electrical parameters at NOCT
Maximum Power Pmax @ NOCT		266	271	275	279.2	283.4
Maximum voltage, Vmpp	(V)	37.62	37.92	38.13	38.36	38.58
Maximum current, Impp	(A)	7.07	7.14	7.21	7.28	7.35
Open circuit voltage, Voc	(V)	46.3	46.6	46.87	47.09	47.31
Short circuit current, Isc	(A)	7.48	7.56	7.61	7.68	7.75
Mechanical data
Length			1998 mm
Width			1010 mm
Height			35 mm/40 mm
Weight			22.7 Kg (35 mm) / 23 Kg (40mm)
Junction box			IP68
Cable and connectors			1200 mm length cable, MC4 & Amphenol compatible connectors
Application class			Class A (Safety class II)
Superstrate			High transmittance arc glass
Cells			72 mono-crystalline PERC solar cells; 5 bus bars
Encapsulation			Low shrinkage PID resistant EVA
Substrate			Tri layer backsheet
Frame			Anodized aluminium frame with twin wall profile
Mechanical load test as per IEC & UL			5400 Pa-front; 2400 Pa-back
Maximum series fuse rating			15 A
