DATA

ELECTRICAL DATA | STC*
CS3U 335P 340P 345P
Nominal Max. Power (Pmax) 335 W 340 W 345 W
Opt. Operating Voltage (Vmp) 38.2 V 38.4 V 38.6 V
Opt. Operating Current (Imp) 8.77 A 8.86 A 8.94 A
Open Circuit Voltage (Voc) 45.7 V 45.9 V 46.1 V
Short Circuit Current (Isc) 9.28 A 9.36 A 9.44 A
Module Efficiency 16.89% 17.14% 17.39%
Operating Temperature -40°C ~ +85°C
Max. System Voltage 1500V (IEC/UL) or 1000V(IEC/UL)
Module Fire Performance TYPE 1 (UL 1703) or CLASS C (IEC 61730)
Max. Series Fuse Rating 20 A
Application Classification Class A
Power Tolerance 0 ~ + 5 W
ELECTRICAL DATA | NMOT*
CS3U 335P 340P 345P
Nominal Max. Power (Pmax) 249 W 252 W 256 W
Opt. Operating Voltage (Vmp) 35.3 V 35.5 V 35.7 V
Opt. Operating Current (Imp) 7.04 A 7.11 A 7.18 A
Open Circuit Voltage (Voc) 42.7 V 42.9 V 43.1 V
Short Circuit Current (Isc) 7.49 A 7.55 A 7.62 A
Mechanical data
Specification Data
Cell Type Poly-crystalline
Cell Arrangement 144 [2 X (12 X 6) ]
Dimensions 2000 X 992 X 40 mm (78.7 X 39.1 X 1.57 in)
Weight 22.6 kg (49.8 lbs)
Front Cover 3.2 mm tempered glass
Frame Anodized aluminium alloy, crossbar enhanced
J-Box IP68, 3 bypass diodes
Cable 4 mm2 (IEC), 12 AWG (UL)
Cable Length 1250 mm (49.2 in), 1670 mm (65.7 in) is optional for single tracking system with leap-frog connection
Connector T4 series
Per Pallet 27 pieces
Per Container (40' HQ) 594 pieces
